Pacific Energy Neo 1.6 Wood Heater

Heats up to 230m²

$4,028.00

NOW IN STOCK

The Canadian made Neo 1.6 wood heater is built to perform!

Designed to burn the least amount of wood, saving you over $1,000.00 per year in wood costs.

Rated as one of the most efficient wood heaters in its class, the Neo 1.6 is able to burn all night long – keeping your home warmer, for longer.

If you are looking for a wood heater that is a stand out, the Neo 1.6 wood heater is the heater for you.

Compare Products

The Neo wood heater is the latest in advancement in wood heating technology.

Since wood heaters have become the main stream heating, there  have been a consistent drive to make wood heaters burn less, burn cleaner, product less smoke, burn longer : all this is achieved in the Neo wood heater range.

Pacific Energy first made wood heaters back in 1974, they started with a focus on how to make fire burn cleaner.

The way to do this, is to focus on the fire first – not the heat.

By increasing the temperature the fire burns at, and having the air the fire needs to burn supplied at a higher temperature, you can increase the performance of fire.

The Neo wood heater uses pre heated air coming in to the fire box : this air comes in at three different points.

First, one third of the air is used for the air wash that goes over the glass to keep it clear of soot, and clean to see though.

The air wash is per-heated to 300+oC  that goes over the glass to give you the cleanest glass you will see on any wood heater

Secondly, is the bellows : inside the firebox, directly under the door opening is bellows

What this does is introduces hot air directly into your fires coals to give them a real boost.

Most wood heaters only have air coming in at the to of the fire, this means you are left with the logs/coals starved of oxygen and leaving your fire with dean, unburnt coals when the fire goes out

Not the Neo wood heater, the bellows ensure your fire is charged with air : its like burning a fire on an old fasion grate and ashtray : fast to get going, making your fire easy to light.

Thirdly is what Pacific Energy Neo is all about, the baffle.

All wood heaters use “secondary air” technology. What this is : by introducing extremely hot air into the smoke your fire produces, you can re ignite the smoke ( which is un- burnt fuel )

This re-ignition does a number of things

– it gives you more heat : the additional flames you get from this re-ignition is heat you would not have have got.

– it reduces the smoke : reducing emissions for greenhouse gasses is the worlds number one long term issue, and wood heaters do produce smoke that does enter the atmosphere : by re burning the smoke, turning it into flames, you are significantly reducing the emissions

In the 1970’s and 1980’s when the wood heater boom took off, there was no real focus here, and for every 1kG of wood you burnt in your heater made in the 1970’s and 1980’s you produced up to 50gms of emissions in to the atmosphere.

In the 1990’s and 2000’s, the introduction of secondary burn made a massive difference, heaters started to produce less smoke : down form 50gms per 1kG of wood – to 5gmrs per 1gk of wood you burnt

The Neo only produced 1.0Grms of emissions per 1Kg of Wood you burn

How they do this is significantly increasing the temperature of the secondly air. Where traditional wood heaters have a round 25mm stainless ( or sometimes steel ) tube with holes under the baffle

This 25mm round tube has air passing through it, and being directly over your fire, it gets hot – the heat heats the air and when it comes out of the holes, this hot air ignites the smoke – creating a secondary burn

The difference is in the NEO wood heaters, rather than a small 25mm tube : the entire top baffle is the secondary air.

The baffle is 900% larger than a single 25mm air tube : thus this significant surface area increases the temperature of the air passing though this from a traditional 250+oC to over 800+oC

This significant air temperature entering the un burnt smoke ignites the smoke to create an extraordinary increased secondary burn.

Not only is it impressive to see, its actually doing some amazing stuff.

Its re burning more smoke than other heaters, turning this into more heat : the 82% efficiency is almost 30% more heat using the same amount of wood than most other heaters.

This increased efficiency means you now burn less wood, up to 3 tons of wood less per year.

And because this extra heat is coming form the re-ignition of the smoke, you are burning significantly less wood.

The construction of Pacific Energy’s baffle is 304grade Stainless Steel : it comes with a 10year warranty ( no other heater warrants their baffles for more than 12 months… )



wood-heater

24 or 36 month interest free available

Choose between 24 or 36 months interest free
Take home for as little as $28.58 per week (over 36 months interest free*) *Approved applicants only. Fees and T&Cs apply. To find out more, and get pre-approval click here.

Live in the suburbs and want a wood heater

If you live in the suburbs and have always wanted a wood heater, the Neo 1.6 high efficient wood heater is not only the perfect fit, but will same money and space.

Amazing flames - like no other

The Neo is designed to burn not just wood, but to burn the smoke as well.
Not only giving you less smoke - but an amazing afterburn flame to watch.
Glass size: 390mm wide x 245 tall
Firebox: 435mm wide x 240mm high x 320mm deep

Saving you up to $1,000.00 each year

Your Neo 1.6 will burn two tonnes less wood every year, saving you up to $1,000.00 annually in wood purchases.
The Neo 1.6 is tested with maximum efficiency of 80% - and an impressive average efficiency of 75%. This is equal to a 6 star rating.

Overnight Burn

The Neo 1.6 is an approved clean burning wood heater, meaning you can achieve overnight burn.
You can easily get over 12 hours of burntime on a full load of wood with the air slider shut down all the way.

2025 approved

With changes in wood heating emissions coming in 2025 - the Neo 1.6 is already approved.

The Neo1.6 is tested at 0.7g or a 5.5 star rating (that's 70% cleaner burning than most wood heaters in this class).
Less smoke in the atmosphere is better for everyone.

Heating Capacity

The Pacific Energy Neo 1.6 has the heating capacity to heat up to a 230m² open plan home.

What Makes the Neo So Different?

What makes the Neo so different?
It's the baffle.
Watch this video to understand why the Pacific Energy Neo Baffle is so different to all other wood heater baffles.

Built Like Nothing Else

Look inside any Pacific Energy wood heater and you will see there why these are no ordinary wood heaters.

The baffle build quality is backed with a 10 year warranty, giving you security of the baffle's quality.

EBT (Extended Burn Time)

If you are installing your heater into a two story home, or have more than 4m of flue, your wood heater may struggle to draw.
Exclusive to Pacific Energy (and standard in the Neo wood heaters), is their patented EBT (Extended Burn Time) technology. This automatically adjusts the draw to give your Neo the longest possible burn times.

Fully Firebrick Lined

Fully fire brick lined means the walls and floor are completely covered with firebricks.
This means 60% more thermal mass than other wood heaters.
A hotter fire means a cleaner burning fire.

close with confidence

The "lock-style" door handle is so smooth to use.
Every time you open and close the Neo door, you feel the quality, and that satisfying click assures that the door is properly closed.

Stop dust in your home with the ash dump

Standard with the Neo 1.6 wood heater is Pacific Energy's ash dump.
No more dust when cleaning out your wood heater.

Colour

The Neo 1.6 side panels are available in a range of colours, from a traditional painted Metallic Black to a choice of vitreous enamel; Ivory, Red, Titanium, and enamel Black.

Optional Fan With A Difference

The optional Two Speed fan has a unique feature - It's automatic!
In Automatic mode, the fan will only turn on when the heater reaches temperature, no more blowing cold air around the house.

For the Best Results

For the best results we recommend installing your Neo 1.6 with an Outside Air Kit and an Insulated Flue Kit.
This gives you an additional 8% performance from your Neo and eliminates cold drafts in your home.

How To Stop Draughts In Your Home

No matter which heater you choose, all wood heaters require air and that can cause draughts in your home.
This video goes over two simple things you can do to prevent cold draughts.

Review

The Neo range of heaters are amazing. The way the air is pre-heated as it enters the firebox gives the Neo the most impressive flames we have ever seen.
The build quality is true Canadian and the burn time is more then "just overnight" but 12-15 hours on a full firebox load. Our score is 9.9/10!


Pricing




Options






Flue Kit




Out Side Air


Fan


Flashing




Hearth




Total Price $0.00 (inc GST)
Please note that this pricing is indicative only and does not represent a quotation, nor does it include installation or delivery unless explicitly specified.

Specification

dimensions
height 940mm
width 690mm
depth 512mm
Clearances
Style Options
Color Options Black, Red, White, Enamel Black, Titanium
Rear clearance to combustible 120mm
Side clearance to combustible 250mm
Corner clearance to combustible 150mm
Burn time 12 - 15 hoursh
Info
flue size 150mm
min flue height 4mtrs
hot water No
heating capacity 230m2
Average efficiency 75%
Max efficiency 82%
Emissions 0.7grms
wood length 400mm
stove weight 154kg
Made in Canada
Fan Yes - optional

Warranty

10 year warranty on firebox, door glass, and baffle | Lifetime warranty on enamel finish | 3 year warranty on electrical parts (including fan)
